Technical specifications:
1 Features
2 Model Power shift FG25T
3 Load capacity kg 2200
4 Load center mm 500
5 Power unit Gasoline
6 Operator type Driver/seat
7 Tire type Front/rear Pnenumatic
8 Wheel Front/rear 2/2 Dimension
9 Max. lifting height mm 4350
10 Free lift mm 995
11 Fork size L*W*T mm 1070×122×40
12 Tilt range Mast forward/backward deg 6/12
13 Overall length(without fork) mm 2530
14 Total width mm 1150
15 Mast height (fork lowering) mm 1995
16 Overall height fork raised With backrest mm 5380
17 Height to head guard mm 2120
18 Turning raduis(outside) mm 2240
19 Front face of fork to front axle mm 450
20 Min. right angle stacking aisle without load length&clearence mm 2690 Performance
21 Speed Max Travelling full/no load km/h 17/19
22 Lifting full/no load mm/s 550/580
23 Lowering full/no load mm/s 450/550
24 Max.drawbar pull Power shift
full/no load kg 1670/830 Manual shift
full/no load kg 1700/830 Weight
25 Gradeability at 1.6km/h Power shift full/no load 22/18
Power shift full/no load 22/18 26
Truck weight kg 3815 Frame
27 Weight distribution Full load front/rear kg 5370/710
28 No load front/rear kg 1390/2190
29 Tires Number front/rear 2/2
30 Model front axle 7.00-12-12PR
31 rear axle 6.00-9-10PR
32 Wheelbase mm 1600
33 Tread Front/rear mm 970/970
34 Ground clearence At lowest point(mast) mm 110
Frame mm 115 Engine
35 Brake Service brake Hydraulic-foot peda
Parking brake Mechanical-hand lever
36 Battery Voltage/capacity V/AH 12/60
37 Engine Model Nissan K21
Rated power PS(kw/rpm) 47/2250(34.6/2250)
Rated torque kg-m max.(N.m) 15.7/1600(153/1600)
Number of cylinders 4
Placement L 2.065
Fuel tank capacity L 70
38 Transmission Speed forward/backward
Power shift T/M 1-1 power shift T/M
39 Operating pressure Hydraulic system pressure kg/cm² 180
